Abstract

This page presents a comparison of DeepLabv3, FCN, MOG2 and GMG in extracting human silhouettes from videos. Three videos were recorded: (a) static camera, constant illumination (b) moving camera, constant illumination and (c) static camera, dynamic illumination. The ResNet-101 based models were used to semantically segment human pixels in each frame to create a silhouette binary mask. Binary maps from manual rotoscoping was used as a ground truth to generate a confusion matrix producing the mean F-score of 0.96, 0.95, 0.26 and 0.22 at the mean FPS of 1.00, 1.20, 15.76, and 8.23, respectively.

Visual Comparison of Each Tested Method

Visually, for test videos 1 and 2, the CNN methods produce nearly perfect segmentation results. They are less accurate for the third video where the limbs of the subject appear to be missing. For all 3 test videos, the computer vision methods deliver poor results where there are holes in the foreground, and the background is wrongly detected as a human silhouette.

Typical Process

There are many solutions currently available and in-use. It is difficult for a computer vision algorithm to compensate for changes in lighting and camera movement, limiting the use case to static and uniform backgrounds [3]. Due to that, most computer vision techniques are imprecise and do not properly extract all foreground elements [6]. Generally, most algorithms have three main processes to achieve silhouette extraction [4]:

Dataset

A custom test dataset was deemed most suited for this report to compare the tested methods fairly and extensively. The following criterion was created:

• Only human subject(s). Preferably the same human subject for each video to achieve consistency and fair comparison. Other categories of living or non-living objects are unnecessary for the purpose of this report.
• Continuous video with no breaks. The video must have a frame rate of 30 which is commonly used in video conferencing applications. The video must contain at least 1 second of footage so that the methods tested may model the background.
• Binary map ground truth. Each video must have a corresponding binary map to act as the ground truth to perform accuracy calculations. The binary map may be selected frames at a fixed interval to reduce computational complexity as well as manpower needed for manual rotoscoping.
• Variable difficulty in the form of camera movement, background complexity, illumination changes, etc. The first video should ideally be as simple as possible to act as a best-case scenario. The various difficulties aim to test the limits of each method and find the failure cases.

Flowchart

The .VideoCapture function from OpenCV is used to capture video files from a device or file source. Then, the .read function is used to extract each frame individually. Using the DeepLab pretrained model, a mask is created of the human pixels present in the frame. Next, a bitwise operation is applied to the frame by multiplying the source with the generated mask. The resulting frame is then displayed to the user via the .imshow function.

Functions

Results

To determine the accuracy of each method, a confusion matrix is calculated as seen in Table 4.1. For each frame, the binary map of the output is compared to the ground truth. The silhouette pixels are pure white (255 intensity value), while the background pixels are pure black (0 intensity value). When a pixel is part of the silhouette in the ground truth, and the output pixel corresponds in location and value, this is marked as one true positive pixel. When the output pixel is determined to be part of the silhouette when it is actually the background, this is marked as one false positive pixel. When the ground truth pixel is a silhouette, but the output pixel fails to identify as such, the pixel is marked as a false negative. When the pixel is a background pixel in both the ground truth and output, this is marked as a true negative.

Accuracy

DeepLab3 leads with the highest overall F1-score of 0.96 across all three test videos. It produces a near-perfect silhouette extraction of 0.99 for the first test video, a slightly reduced score of 0.96 for the second test video and struggles slightly with the third test video at 0.94. As FCN is DeepLabv3’s predecessor, it was expected to perform marginally worse. However, its performance is just slightly DeepLabv3’s.

FCN’s results are 0.1 less accurate across all categories. MOG2 and GMG perform the same for the first test video, at an F-score of 0.46. Both perform the worst in the second test video as the background was constantly moving which cannot be handled by the background modelling technique they both share. At 0.14 and 0.09 F-scores respectively, the result is extremely poor. They perform slightly better with the third test video at 0.17, and 0.11 respectively, as the background is now constant with the camera mounted to a tripod. The computer vision techniques are far inferior compared to the ResNet-101 convolutional networks, performing 4x worse overall.

Speed

FPS is chosen over inference time or time per frame as the speed metric because for FPS is more common for video applications and can act as a metric to determine real-time processing speed. The mean FPS of each method is recorded on a per-frame basis. In Table 4.3, the FPS of every frame processed is recorded individually to analyse for a per-frame variance in performance. All three methods have the approximate first frame FPS of 6.23E-10. The FPS of the first frame is excluded as it is significantly longer due to the overhead of initialization. Much of this time is taken by OpenCV to capture a video file and load it as a stream. The time taken to load the CNN models are excluded from the FPS calculation.

The variance of both CNN methods is very low, averaging at 0.0009 FPS. The variance of both computer vision methods are significantly higher compared to the CNN methods, at 0.4158 FPS. This is because ResNet-101 performs identical processing on each input frame regardless of the content, where convolution and deconvolution is applied uniformly which results in near identical processing times. For the computer vison methods however, processing is done with a background modelling approach. Depending on the nature of the background, processing time varies significantly.

The speed results are the opposite of the accuracy results. DeepLabv3 performs the worst among the bunch, at the average of 1.00 FPS. FCN performs 20% better than DeepLabv3, at 1.20 FPS. This is because DeepLab introduced atrous convolution which is not present in the FCN model which carries a performance overhead. MOG2 and GMG are significantly faster at 15.76 and 8.23 FPS, respectively.

Performance Tradeoff

When comparing speed and accuracy, computer vision methods have a major advantage in terms of speed, while CNN methods triumph in accuracy. Among the 4 methods discussed, there does not seem to be a middle ground compromise where both speed and accuracy is balanced. The methods only excel in one metric or the other. Between DeepLabv3 and FCN however, FCN is 20% faster with only a 1% accuracy penalty. FCN is the preferred option in this scenario when using a CNN based approach. For the statistical background modelling approaches, MOG2 is superior to GMG as it is 91% faster and 18% more accurate.

Conclusion

Convolutional neural networks are an abundant class of models that tackle numerous pixelwise tasks. CNNs excel in semantic segmentation in images which can be adapted to extract human silhouettes from videos. The proposed ResNet-101 based solutions using DeepLabv3 and FCN demonstrate accurate results with the overall F-score of 0.96 albeit with a significant performance penalty, running at 1.00 and 1.20 FPS compared to 15.76 and 8.23 FPS of MOG2 and GMG, respectively. A trade-off method that performs well in terms of both accuracy and speed could be found to act as a middle ground to be used in real time applications. A newer CNN based approach such as Faster R-CNN or Context Encoding Network (EncNet) could be explored to address the current limitations.

THANK YOU FOR READING!

The Research

MOBILE TRAVEL has become a significant trend due to the emergence of smartphones and mobile technology. Existing researches show that the integration of location-based services (LBS) is potentially adding significant values to the mobile tourism industry. The purpose of this study is to develop a location-based mobile application for theme park visitors to enhance their visiting experience. The application of location-based solutions such as  interactive map, push notification services with geofencing and augmented reality tour guide will be involved in this study. Google Map SDK for Android, Google ARCore Sceneform, GeoFire and SQLite methodology is adopted to build the application. An online survey is conducted to evaluate the user acceptance for the mobile application by sending Android Package Kit (APK) to the users. The result shows that majority of respondents had a positive attitude towards the application and agreed that the application will enhance their park visiting experience. The conclusion can be drawn that the application can be further improved with features that contribute to the digitalization of outdoor parks or other fields in mobile tourism.

Tools & Techniques

Platform, Programming Language, Tools and Techniques

• Android Studio 3.4 (Java, xml)
• Android Map SDK
• ARCore SDK
• Ground Overlay
• Google ARCore Sceneform

Database

• SQLite
• GeoFire

Hardware

• Android Phone (Android 7.0 or higher)

Why am I researching in this area?

➀

I stayed at a hostel which nearby the amusement park when I studied in the university, I can hear the laughs and fun from my balcony everyday. One day my lecturer assigned us to do a mobile application project, then there’s a sudden thought popped into my mind: let’s build a theme park application! In the midst of assignment, I found that building mobile application can be fun and interesting. After the project, my supervisor, Dr Lau suggested me to carry it on and enhance the development with location-based features and augmented reality in my final year project…

➋

Application’s Major Functionalities

INTERACTIVE MAP

GEOFENCING NOTIFICATION

AR GUIDE/FEATURE

➂

Results & Findings

To evaluate the prototype, an online survey is conducted for the user acceptance testing by sending APK to the users and collecting their feedback through Google Forms. The survey is collecting their feedback on the user interface design,  usefulness and ease-of-use of the application, perceived enjoyment and attitude towards the developed application with the 5-likert scale. Overall, 12 responses are collected in the survey.

❹

Conclusion

➎

The results from the user acceptance survey also show that the respondents are satisfied with the functionality of the application and agree that the application will enhance their visitor experience. The possibility to allow visitors make interaction with the application by finding or locating a point of interest or even making food order using location-based AR has showcased that how an AR visitor application can help in improving visitor experience which also contribute as the first step to the theme park digitalization.

The suggestions from the user testing are also can be considered as the input for potential future work. Also, it is important to think about suitable strategy to attract visitors to download the application. Commonly, visitors only need the application when they are inside the park and after their visits, they tend to uninstall the application. Ideas can be generated to encourage users to continue using the application so that they may return to the theme park soonest possible. In this way, the application can also become a marketing and engagement tool which will in return increase revenue.

 —— Aknowledgement ——-

I would like to express my very great appreciation to Assoc. Prof. Dr Lau Sian Lun, my research supervisor, for his ehthusiatic encouragement and guidance support of this research work. I wish to thank Lancaster UC Conference for giving me this precious chance to present my work. I would also like to thank Sunway Lagoon Management and the 12 anonymous respondents that participate in the survey. My grateful thanks are also extended to Ms. Lim Woan Ning, one of my favourite programming lecturer in Sunway University for always being helpful and understanding. Besides, I very much appreciate to my friends Ng Xin Hui, Choo En-Ni, Yeap Khor Chin, Liew Hui Yong, Lee Pui Yen, Tang Shu Jian, Tan Chen Lin and Kok Tim Joon who are always supporting me for every decision I made. Finally, I wish to thank my parents and family members for their support and encouragement throughout my study.
